Teltonika charging station - 7,4kW, 1 phase with Type 2 cable
Free shipping on all orders worldwide
Guarantee safe & secure checkout
Teltonika charging station - 7,4kW, 1 phase with Type 2 cable
V2C Trydan Specifications
Warranty:
- 36-month warranty included with the product.
Dynamic Power Management:
- Dynamic load controller required to access current state subsidies (+200 EUR).
Connectivity:
- WiFi: 2.4 GHz b/g/n connection.
- Bluetooth: For remote control and management.
- NFC reader for easy device pairing.
- Ethernet: RJ45 connection.
- 4G/LTE (CAT1), 3G, 2G (optional).
Environmental Specifications:
- Operating Temperature: -30°C to +50°C.
- Humidity: Up to 95% RH, non-condensing.
Cable Details:
- Cable Length: 5 m.
- Type 2 IPSS socket.
Charging Specifications:
- Maximum Output Power: 7.4 kW.
- Single-phase: 230 V (±10%) at up to 7.36 kW with 32A.
- Three-phase: 400 V (±10%) with dynamic configuration.
Safety and Compliance:
- Certifications: CE & UKCA compliant, 2014/53/EU, 2011/65/EU, IEC/EN 61851-1, 61851-21.
-
Integrated Protection Features:
- Output voltage and current monitoring.
- Temperature monitoring.
- Input voltage monitoring.
- Integrated RCD (30 mA AC / 6 mA DC) compliant with IEC62752:2016.
- Ground fault detection.
- Impact resistance (IK10).
Frequency and Temperature Sensors:
- Operating Frequency: 50/60 Hz.
- Temperature Range: All main components rated for -30°C to +50°C.
Status Indicators:
- LEDs indicating charger status.
- Static and dynamic load balancing features.
The V2C Trydan combines advanced technology with robust safety features, ensuring reliable and efficient charging for your electric vehicle.
